ILT-110 Series Inductive Linear Position Sensors || ATEK || Made in Türkiye

Touchless inductive measurement technology
Absolute working principle
Analog, SSI, CANopen, RS-232 or RS-485 interface
Versatile mounting
Durable, solid body
IP67 protection

Measurement with non-contact and inductive principle in a robust profile; Infinite mechanical life since it works without mechanical friction, absolute, that is, the feature of not losing position information in case of a power cut.

Measuring Range Output Protection Linearity  Datasheet
 100 – 1000 mm Analog(Current or Voltage), SSI, CANopen, RS-232, RS-485 IP 67 ≤±%0.025 FS
  • Inductive measurement technology
  • Absolute working principle
  • Magnetic field resistant
  • Touchless measurement
  • Status LED
  • Versatile mounting
  • 1 µm resolution
  • 500 Hz high update rate
  • Shock and vibration resistance
  • Analog, SSI, CANopen, RS-232 or RS-485 interface
  • IP67 protection class
Marka

Atek

Stroke Value

Between 100 mm… 500 mm in steps of 50 mm
Between 500 mm… 1000 mm in steps of 100 mm

Resolution

Analog: 16 bit
SSI: 1…1000 µm
CANopen: Position resolution:1 μm min. / Speed resolution:10 µm/s min.

Signal propagation delay

2, 3, 4, 5, 6, 8, 10 ms (according to filter selection)

Reproducibility

< ± %0.012 FS (when the signal propagation delay is 10 ms)

Absolute Linearity

≤ ± %0.025 FS (min. ± 100 μm) (when the signal propagation delay is 10 ms)

Linearity

% 0,1 – % 0,4 FS

Output Signals

Analog: 0-10V, 0.5-4.5V, 0-5V, 0-20 mA, 4-20 mA
CANopen
SSI

Output update rate

500 Hz max.

Suuply Voltage

Analog : 15…33 VDC
CANopen and SSI : 8…33 VDC

Power consumption

0.5W

Overvoltage protection

33VDC

Short circuit protection

Yes

Mechanical Fixing

Adjustable (movable) mounting clamps

Protection class

IP67

Operating Temperature

-20°C … +70°C

Life

Mechanically unlimited

Electrical connection

Cable or connector
