Hydrostatic Level Control Sensors

AISI 316L stainless steel body
Different level measurements from 1 meter to 100 meters
4-20mA or 0-10 VDC analog output options
RS-485 Modbus output option
±0.2% accuracy
Oil- and fuel-resistant model option
IP68 protection class
Compact structure

Standard diaphragm; submersible level transmitters; durable for harsh conditions; stainless steel body; high precision; EMC and reverse polarity protection; Suitable for use with oils and fuels, wells, water tanks, lake or river level monitoring, reservoirs, wastewater, and greywater.

Datasheet

Measuring Range	Membrane	O-Ring	Output	Protection	Accuracy	Datasheet
Between 0-100 mbar and 0-25 bars  From 1 meter to 100 meters depth	AISI 316L	NBR or Viton (FKM)	4-20 mA, 0-10 VDC, RS-485 Modbus	IP68	%0,2

1.4462 (duplex), 316L or titanium body
High corrosion resistance, suitable for use in salt water
Different level measurements from 4 meters to 100 meters
4-20mA or 0-10 VDC analog output options
± 0.3% accuracy
IP68 protection class

Standard diaphragm; submersible level transmitters; durable for harsh conditions; dublex, 316L or titanium body; high precision; EMC and reverse polarity protection; Suitable for applications such as seawater, saltwater, grey water, waste water etc.

Datasheet

Measuring Range	Membrane	O-Ring	Output	Protection	Accuracy	Datasheet
Between 0-400 mbar and 0-25 bars  From 4 meters to 100 meters depth	Ceramic	NBR	4-20 mA or 0-10 VDC	IP68	%0,3

AISI 316L stainless steel 19 mm slim body
Different level measurements from 1 meter to 100 meters
4-20mA or 0-10 VDC analog output options
±0.3% accuracy
IP68 protection class
Compact structure

Submersible level transmitter with 19 mm slim body; durable for harsh conditions; 316L stainless steel body; high precision; EMC and reverse polarity protection; Suitable for general applications such as lake or river level, wells, water tanks etc.

Datasheet

Measuring Range	Membrane	O-Ring	Output	Protection	Accuracy	Datasheet
Between 0-100 mbar and 0-25 bars  From 1 meter to 100 meters depth	AISI 316L	Viton (FKM)	4-20 mA or 0-10 VDC	IP68	%0,3

AISI 316L stainless steel body
Different level measurements from 1 meters to 100 meters
4-20mA, 0-10 VDC or 0.5-4.5 VDC analog output options
Suitable for oils and fuels
±%0,3 accuracy
IP68 protection class
Compact structure

Standard diaphragm; submersible level transmitters; durable for harsh conditions; 316L stainless steel body; high precision; EMC and reverse polarity protection, Suitable for applications such as oils and fuels

Datasheet

Measuring Range	Membrane	O-Ring	Output	Protection	Accuracy	Datasheet
Between 0-100 mbar and 0-25 bars  From 1 meter to 100 meters depth	AISI 316L	Viton (FKM)	4-20 mA, 0-10 VDC, 0.5-4.5 VDC	IP68	%0,3

Special design for textile sector
Piezoresistive working principle
316L stainless steel housing
Different models between 100 mBar and 600 mBar
Analog 4-20mA / 0-10V and so on different outputs
±0.3% F.S accuracy
IP65 protection class
Compact construction

Special design for textile sector; stainless steel body; air isolated mounting; high sensitivity; EMC and reverse polarization protected; small and compact design

Datasheet

Measuring Range	Output	Protection	Accuracy	Body Diameter	Datasheet
Different models from 0…100mbar to 0…600mbar	4-20 mA, 0-10 VDC, 0-20 mA, 1-6 VDC, 0-5 VDC, Ratiometric etc.	IP65	±%0,3 F.S	23mm
